Application scale:
The series diesel engine mainly applied all kinds of light duty trucks, cross-country vehicle, pick-up, light duty bus, MPV and military truck ect.
The main technical performance:
It adopted Nissan technology, and it is with international advanced level. There are four kinds of productions: naturally aspirated engine, EGR, supercharged, and supercharged inter-cool diesel engine.
Small vibration, low noise, powerful and good comfort.
Low emission, EGR engine reached Europe II. Supercharged and supercharged inter-cool diesel engine is better Europe II.
It is with excellent quality, reliability and durable. The main spare part all produced by the imported machine-center.
The main technical parameters of CYQD32Ti | |
Model |
QD32Ti |
Type |
4 cylinders in line, vertical, water-cooling, 4 stroke |
Aspiration |
turbocharged, aftercooled |
Ignition Order |
|
Bore * Stroke |
99.2mm (3.9 inch) x 102mm (4 inch) |
Displacement |
3.153 L ( 192.4 in3 ) |
Compression Ratio |
22 : 1 |
Power Rating |
101.5kw (138hp) |
Rating Speed |
3600rpm |
Peak Torque |
313 N.m (231 lb.ft) |
Peak Torque Speed |
2000rpm |
Idle Speed |
800±50 rpm |
Maximum Steady Idling Speed |
4700±100rpm |
Net Dry Weight (kg) |
275kg |
Overall Dimensions |
721*701*665mm |
